Eaton TRGF20V Tamper-Resistant Self-Test GFCI Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Back, Side Wiring, Ivory
- Color: Ivory
- Current Rating: 20 A
- Dimensions: 4.19 in H x 1.69 in W
- Grounding Type: Automatic
- Material: Polycarbonate/Steel/Thermoplastic/PVC
- Model #: TRGF20V
- UPC #: 032664013126
- SKU: 2991362
Your shopping list will be used for pickup in-store
Product Details
Eaton Tamper-Resistant Self-Test GFCI Receptacle, 125 V, 20 A, Number of Poles: 2, Short Circuit Current Rating: 10 kA, Grounding Type: Automatic, Number of Wires: 3, Wire Size: 14 to 10 AWG, Wiring Type: Back, Side, NEMA Rating: NEMA 5-20R, Operating Temperature: -35 to 66 deg C, Polycarbonate/Steel/Thermoplastic/PVC, Ivory, Dimensions: 4.19 in H x 1.69 in WKey Features
- Slimmer design for easy installation, leaving more room for wires in the box
- Automatically self-tests periodically to ensure GFCI protection
- GFCIs incorporate lock out functionality to protect against mis-wired line load connections and GFCI circuitry damage
- Wider button wells for easy test and reset
- Intuitive LED status indicators for trip and end of life states
- Clean, modern industrial design with reduced top housing markings and neutral text direction on buttons
- Meets and exceeds 10 kA short-circuit testing and underwriters laboratories
- Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
- External back wire clamps provide visual confirmation of secure termination
- Line side terminals are backed out and staked for fast installation
Item Specifications
| Color | Ivory |
|---|---|
| Current Rating | 20 A |
| Dimensions | 4.19 in H x 1.69 in W |
| Grounding Type | Automatic |
| Material | Polycarbonate/Steel/Thermoplastic/PVC |
| Nema Rating | NEMA 5-20R |
| Number of Poles | 2 |
| Number Of Wires | 3 |
|---|---|
| Operating Temperature | -35 to 66 deg C |
| Short Circuit Current Rating | 10 kA |
| Voltage Rating | 125 V |
| Wire Size | 14 to 10 AWG |
| Wiring Type | Back Side |
